Daikin AURORA 18,000 BTU (Up to 24,000 BTU) 21 SEER2 Ductless Mini Split Heat Pump and Air Conditioning Inverter Multi-Zone Condenser with Drain Pan Heater - 2MXTH18AVJU9
Daikin's Multi-Zone Systems are ideal for multi-room applications desiring individual room comfort in a space-saving design, with the ability to connect two indoor units to a single outdoor unit. Systems offer energy efficiency levels up to 21 SEER2 and 10 HSPF2 for enhanced home comfort and energy savings. Daikin AURORA Multi-Zone systems offer enhanced capacity in cold ambient conditions. Suitable for both new build and renovation projects, Daikin Multi-Zone Systems are the smart, reliable solution for your home.
Features:
- Includes drain pan heater
- Up to 24,000 BTU's - See Combination Capacity Chart here
- Pre-Charged for 98.4 ft of line set length
- World-renowned Daikin Inverter Variable Speed compressor technology
- Designed to deliver enhanced capacity in cold ambient conditions
- Up to 114% rated heating capacity at 5°F / -15°C and operate efficiently as low as -13°F ambient temperature (See full operating temperature details here)
- Energy Efficient - UP to 21 SEER2 / 10 HSPF2 / 12 EER2 for ultra-efficient cooling and heating operation and reduced operating costs compared to conventional lower-efficiency systems
- 2 Zone enhanced Capacity Multi-Zone
- R-32 Refrigerant Type
Specifications:
Brand |
Daikin |
Model |
2MXTH18AVJU9 |
Warranty |
|
BTU |
18,000 BTU (Up to 24,000 BTU) - See Combination Capacity Chart here
|
Power Supply |
|
COP@5°F |
W/W: 1.8 |
EER2 (Btu/W·h) |
12.0 |
SEER2 |
21.0 |
HSPF2 |
10.0 |
Casing Color |
Ivory White |
Compressor |
|
Refrigerant Oil |
|
Refrigerant |
|
Airflow Rates |
|
Fan |
|
Starting Current |
17 A |
Dimensions (H × W × D) |
29-1/2 × 34-1/4 × 12-5/8 inches (750 × 870 × 320 mm) |
Packaged Dimensions (H × W × D) |
32-1/16 × 40-5/16 × 16 inches (814 × 1,024 × 406 mm) |
Weight (Mass) |
140 lbs (64 kg) |
Gross Weight (Gross Mass) |
148 lbs (67 kg) |
Sound Pressure Level |
|
Piping Connection (inches) |
|
Heat Insulation |
Both Liquid and Gas Pipes |
No. of Wiring Connections |
3 for Power Supply, 4 for Interunit Wiring (Including Ground Wiring) |
Max. Interunit Piping Length |
|
Amount of Additional Charge oz/ft(g/m) |
0.22 (20) (98-3/8 ft (30 m) or more) |
Max. Installation Height Difference |
|
Conditions Based on Cooling |
|
Conditions Based on Heating |
|
Resources |
