Daikin ATMOSPHERA 9,000 BTU 27.4 SEER2 Ductless Mini Split Inverter Air Conditioner Heat Pump System 208/230V (R-32) - FTXM09WVJU9 / RXM09WVJU9
The Daikin ATMOSPHERA Single Zone System is ideal for spot cooling and heating needs in residential and commercial spaces that require heating and cooling even in extreme ambient temperatures. In addition, Daikin ATMOSPHERA is an effective source of heat to offset old, inefficient furnaces or boiler systems.
The Daikin ATMOSPHERA system is an Inverter unit that runs continuously but adjusts the compressor’s speed to meet the demand. An inverter is energy saving technology that eliminates wasted operation in air conditioners by efficiently controlling motor speed. Because it maintains the temperature consistently, your space will no longer feel too hot or too cold. Compared to non-inverter type HVAC systems, systems equipped with inverters have less power loss and can save up to 30% or more in energy.
Why choose the Daikin ATMOSPHERA?:
- Energy Efficient: 27.4 SEER2, 11.2 HSPF2, and 16.3 EER2 for ultra-efficient cooling and heating operation and reduced operating costs compared to conventional lower efficiency systems.
- Cooling Range: Up to 100% rated cooling capacity at 115°F (46°C).
- Heating Range: Up to 100% rated heating capacity at 5°F WB (-15°C WB) and confirmed continuous operation as low as -13°F WB (-25°C WB) ambient temperature.
Ideal solution for:
- Renovations, remodeling and new construction.
- Sun rooms, basements, attics, garages, hot or cold rooms, etc.
- Rooms where floor space comes at a premium or is not available for other application.
- Ceiling void or attic does not allow for a viable duct run option.
- Cooling Only models are an excellent value for space(s) not requiring heating.
Aligning with Goals of:
- Decarbonization and Electrification — moving towards clean energy: An effective source of heat to comfortably offset older or inefficient sources of heat using fossil fuels.
- Lower GWP refrigerant — reduce emissions at the source: Utilizing a refrigerant with lower Global Warming Potential (GWP) compared to conventional refrigerants.
- Sustainability: Easy to top off, or clean and reuse on-site and easy to reclaim and recycle.
Innovative technology:
Wide Operation Range: Whatever the climate, Daikin ATMOSPHERA systems can provide quiet and energy-efficient comfort to single and multi-family homes throughout North America.
For those hot summer days - Up to 100% rated cooling capacity at 115°F (46°C):
-
- Hybrid Cooling reduces humidity without over cooling the space
- CLEAN operation dries the interior of the indoor unit to reduce the amount of condensation present
- COMFORT MODE directs air horizontally in cooling to prevent cold airflow from being blown directly onto the body
For those cold winter nights - Up to 100% rated heating capacity at 5°F (-15°C), operation down to -13°F (-25°C):
-
- COMFORT MODE directs air downwards in heating to drive warm air to the bottom of the room
- HOT START reduces cold drafts when first operating in HEAT mode
Features:
- Econo Mode: Limits the maximum operating current and power consumption of the outdoor unit by approximately 30% during start-up. This saves energy and reduces the load on the electrical circuit when multiple electrical devices are used simultaneously.
- 3-D Airflow: Combines vertical and horizontal autoswing to circulate cool/warm air to the corners of large spaces.
- Simplified Maintenance: The indoor unit has been re-designed for easier removal of the drain pan (compared to other wall-mounted units).
- Powerful Operation: Pushing the POWERFUL button on the remote control gives you a boost in cooling or heating power for a 20-minute period, even if the unit is already operating at high capacity.
- Comfort Mode: When cooling, the flap positions itself horizontally to keep cold airflow from being blown directly onto the body. When heating, the flap turns vertically downwards to drive warm air to the bottom of the room.
- Daikin App: With the Daikin Comfort Control app you are always in control. You can use your tablet or smart-phone to access your Daikin ATMOSPHERA system via the internet, no adaptor required.
- Intelligent Eye: An infrared sensor with the ability to sense movement in the room. If the room is empty for 20 minutes, it changes the set point to start saving energy.
- Hybrid Cooling: Dehumidifies efficiently even in low cooling loads, and maintains dehumidification effect after the target temperature is reached.
- CLEAN Operation: The CLEAN function dries the interior of the indoor unit to reduce the amount of condensation present. When COOL or DRY operation is performed, condensation may occur inside the air conditioner. It is recommended to dry the inside of the air conditioner using CLEAN operation.
- Increased Factory Charge and piping allowances: Daikin ATMOSPHERA is pre-charged to serve piping lengths up to 49 ft. (15m), a 50% increase in pre-charge coverage compared to previous models.
How the Daikin ATMOSPHERA system and R-32 help elevate projects and offer efficiency:
- Up to 18% more efficient: Up to 12% higher SEER and up to 18% higher HSPF (compared to R-410A Daikin LV Series).
- More thermal capacity: Up to 21% higher cooling capacity at 115°F DB and 51% higher max heating capacity at -13°F WB compared to R410A Daikin LV Series and R-410A Daikin AURORA units)
- Designed to draw less electricity: Up to 30% improvement in full load cooling EER and up to 14% improvement in full load heating COP (compared to R-410A Daikin LV Series and R-410A Daikin AURORA systems).
- Uses less refrigerant: Up to 41% less factory refrigerant charge than a similar Daikin LV Series R-410A system.
- Efficient in harsh conditions: Up to 14% higher COP at 5°F (compared to Daikin AURORA R-410A systems).
Options for Controlling your Daikin ATMOSPHERA:
The Included Remote Control:
Daikin systems have an available infrared remote controller allowing you to access all functions at the click of a button.
Daikin Comfort Control App - Control your Daikin ATMOSPHERA From anywhere in the world. Or your living room:
It can happen to anyone. You forgot to change the temperature of your Daikin ATMOSPHERA heat pump system before leaving the house, or you will be delayed returning home and wish to avoid needlessly heating or cooling your home. What in the past would have resulted in wasted energy is no longer a problem. With the Daikin Comfort Control App, you are always in control. You can use your tablet or smart-phone to access your Daikin system via the internet.
Daikin DKN Plus Interface:
The new Daikin DKN Plus Interface (AZAI6WSPDKC) enables the energy-efficient control of Daikin air conditioners by a third-party thermostat or an automation system. With this interface, third-party devices or systems can control the Daikin ATMOSPHERA indoor unit through the DKN NA App, Cloud API, Modbus®, BACnet™ MS/TP, or thermostat relay contacts. This interface can be commissioned easily through the DKN Cloud NA app via Bluetooth® Low Energy (BLE).
Daikin One+ Smart Thermostat
The Daikin One+ smart thermostat is available for single and multi-zone indoor unit models. With the new translation adaptor, connecting the Daikin One+ smart thermostat provides several user features including remote monitoring, control and geofencing using the Daikin One home app, Google, and Amazon voice assistants.
Daikin One Touch Smart Thermostat:
A great control option for Daikin single and multi-zone systems. With customizable settings and the power to wirelessly control the system from anywhere, homeowners may never want to change their thermostat manually again. However, the touchscreen interface supports a user-friendly experience when they do. Voice control is also possible with compatible Amazon and Google devices.
Daikin One Lite Connected Thermostat:
The Daikin One lite connected thermostat is a perfect solution for most Daikin single and multi-zone products when a wall-mounted smart thermostat is needed. The Daikin One lite connected thermostat can be linked via Wi-Fi to the Daikin One home app for control from an iOS or Android phone or tablet.
Cloud Services:
Once you grant your Daikin contractor access through Daikin One cloud services app, the Daikin cloud can notify your contractor when your system needs maintenance, alert them if your system ever has an urgent need, and provide detailed performance information on your system. The first year of Daikin One cloud services is included with purchase. Ask your Daikin contractor for more information!
NOTE: the handheld remote that comes with some indoor units should not be used together with the Daikin One thermostats.
Warranty:
12 Years Parts Warranty
What's Included:
- 1x Daikin ATMOSPHERA 9,000 BTU Inverter Ductless Heat Pump Condenser (R-32) - RXM09WVJU9
- 1x Daikin ATMOSPHERA 9,000 BTU Wall Mount Air Handler (R-32) - FTXM09WVJU9
- 1x Daikin ATMOSPHERA Wireless Remote Control
Bundled System Specifications:
| Brand | DAIKIN |
| Model |
|
| Warranty |
12 Years Parts Warranty |
| Refrigerant Type | R-32 |
| Capacity Rated |
|
| (Min. ~ Max.) BTU/H |
|
| Max Heat Capacity at 5°F (-15°C) | 11,000 |
| Max Heat Capacity at -13°F (-25°C) | 10,000 |
| COP Rated | 4.6 |
| COP at 5°F (-15°C) | 2 |
| EER2 Rated | 16.3 |
| SEER2 | 27.4 |
| HSPF2 | 11.2 |
| Piping Connections |
|
| Max. Interunit Piping Length | 82-1/64 ft |
| Max. Interunit Height Difference | 65-5/8 ft |
| Chargeless | 49.2 ft |
| Amount of Additional Charge of Refrigerant | 0.22 oz/ft |
| Operating Range - Cooling | 50° - 114.8°F (10° - 46°C) |
| Operating Range - Low-Ambient Cooling* | 14° - 114.8°F (-10° - 46°C) |
| Operating Range - Cooling with Optional Air Adjustment Grille* | -4° - 114.8°F (-20° - 46°C) |
| Operating Range - Heating | -13° - 64.4°F (-25° - 18°C) |
| Power Supply |
|
| Compressor | RLA: 12 |
| OFM |
|
| IFM |
|
| Condenser Resources | |
| Air Handler Resources |
Condenser Specifications:
| Brand | DAIKIN |
| Model | RXM09WVJU9 |
| Warranty |
12 Years Parts Warranty |
| Refrigerant Type | R-32 |
| Charge | 2.16 lbs |
| Airflow Rate Cooling |
High: 1,317 CFM SL/Quite Mode: 1,183 CFM |
| Airflow Rate Heating |
High: 1,296 CFM SL/Quite Mode: 922 CFM |
| Dimensions (H x W x D): |
In inches: 23-7/16 × 33-1/4 × 11-13/16 In mm: (595 × 845 × 300) |
| Weight | 96 lbs |
| Sound Pressure Level |
|
| Resources |
Air Handler Specifications:
| Brand | DAIKIN |
| Model | FTXM09WVJU9 |
| Warranty |
12 Years Parts Warranty |
| Refrigerant Type | R-32 |
| Airflow Rate Cooling |
|
| Airflow Rate Heating |
|
| Fan/Speed/Steps | 5 Steps, Quiet, Auto |
| Air Direction Control | Right, Left, Horizontal, Downward |
| Air Filter | Removable, Washable |
| Dimensions (H x W x D): |
In inches: 11-3/4 × 36-1/4 × 10-13/16 In mm: (299 × 920 × 275) |
| Weight | 29 lbs |
| Sound Pressure Level (H / M / L / SL) |
|
| Resources |
