Daikin AURORA 18,000 BTU Multi Zone Wall Mount Air Handler 230V - FTXV18AVJU9

SKU: FTXV18AVJU9
Your Price:
$967.00 $1,180.00
You Save: $213.00 19%
  • FLASH SALE GOING ON NOW! Save An Extra 15% OFF with Code: FLASH15
  • NO SALES TAX OUTSIDE ARIZONA CALIFORNIA FLORIDA MICHIGAN NEW YORK NORTH CAROLINA PENNSYLVANIA TENNESSEE VIRGINIA
  • EASY RETURNS: 30 Days Money Back Guaranteed
  • FREE SHIPPING: Ships in 2 - 3 Business Days
  • FAST DELIVERY: Arrives in 3 - 7 Days
  • HASSLE FREE DELIVERY: Free Liftgate Delivery + Freight Insurance
  • NEED HELP?: Call 1-800-315-4345
  • AUTHORIZED DEALER: Best Products and Equipment from a Reliable and Knowledgeable Source
Checkout Secure

Quantity Remaining:

Only 51 Left in Stock.
Order in the next to get it by

Get Extra 15% Off With Code: FLASH15 - Flash Sale Ends:

Days
Hours
Minutes
Seconds

Daikin AURORA 18,000 BTU Multi Zone Wall Mount Air Handler 230V - FTXV18AVJU9

Features:

  • Comfort Airflow: The flow of air will be in the upward direction while in COOL and DRY operation and in the downward direction while in HEAT operation, which will provide a comfortable airflow that will not come in direct contact with people.
  • Powerful Operation: POWERFUL operation quickly maximizes the cooling (heating) effect in any operation mode. In this mode, the air conditioner operates at maximum capacity.
  • On/Off Timer Operation: Timer functions are useful for automatically switching the air conditioner on or off in the morning or at night. You can also use the ON TIMER and OFF TIMER together.
  • COOL/HEAT mode lock: The COOL/HEAT mode lock requires initial programming during installation. The COOL/HEAT mode lock sets the unit forcibly to either COOL or HEAT operation. This function is convenient when you wish to set all indoor units connected to the multi system to the same operation mode.
  • Wireless LAN connection (Wi-Fi): The Wireless LAN connection adapter function requires the Daikin One Home App (available on IOS and Android) for connecting to the air conditioner and controlling it via your smartphone or tablet over your network. Daikin One Home Mobile App allows homeowners to remotely monitor and control their Daikin heating and cooling systems.
  • ECONO: ECONO operation enables efficient operation by limiting the maximum power consumption. This function is useful to prevent the circuit breaker from tripping when the unit operates alongside other appliances on the same circuit.
  • Auto Operation: To automatically select an appropriate temperature and operation mode.
  • Cool Operation: To lower the temperature.
  • Dry Operation: To lower the humidity
  • Heat Operation: To raise the temperature.
  • Fan Only Operation: To circulate air in the room.

Specifications:

Brand Daikin
Model FTXV18AVJU9
Warranty 12 Years - See full warranty details here
Wi-Fi Yes
Power Supply

Phase: 1

Hz, V: 60 Hz, 208 - 230 V

Rated Capacity 18 kBtu/h Class
Front Panel Color (Munsell No.) White (N9.5)
Airflow Rates (Cooling)
  • H: 565 cfm (16.0 m³/min)
  • M: 463 cfm (13.1 m³/min)
  • L: 378 cfm (10.7 m³/min)
  • SL: 335 cfm (9.5 m³/min)
Airflow Rates (Heating)
  • H: 717 cfm (20.3 m³/min)
  • M: 572 cfm (16.2 m³/min)
  • L: 452 cfm (12.8 m³/min)
  • SL: 388 cfm (11.0 m³/min)
Fan
  • Type: Cross Flow Fan
  • Drive Input: 0.40 A
  • Speed: 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable, Washable
Running Current (Rated)
  • Cooling: 0.20 A - 0.18 A
  • Heating: 0.29 A - 0.26 A
Power Consumption (Rated)
  • Cooling: 39 W - 39 W
  • Heating: 54 W - 54 W
Power Factor (Rated)
  • Cooling: 93.8% - 92.5%
  • Heating: 89.5% - 89.3%
Temperature Control Microcomputer Control
Dimensions (H × W × D) 11-5/8 × 39 × 10-3/8 inches (295 × 990 × 263 mm)
Packaged Dimensions (H × W × D) 15-3/16 × 43-3/8 × 15-5/16 inches (386 × 1,102 × 389 mm)
Weight (Mass) 27 lbs (13 kg)
Gross Weight (Gross Mass) 37 lbs (17 kg)
Sound Pressure Level Cooling H / M / L / SL: 48 / 43 / 38 / 33 dB(A)
Sound Pressure Level Heating H / M / L / SL: 49 / 42 / 37 / 33 dB(A)
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
  • Liquid: 1/4 inches
  • Gas: 1/2 inches
  • Drain: 5/8 inches
Drawing No. 3D153178A
Note SL: The quiet fan level of the airflow rate setting
