Daikin AURORA 18,000 BTU (Up to 24,000 BTU) 21 SEER2 Ductless Mini Split Heat Pump and Air Conditioning Inverter Multi-Zone Condenser - 2MXT18AVJU9
Daikin's Multi-Zone Systems are ideal for multi-room applications desiring individual room comfort in a space-saving design, with the ability to connect two indoor units to a single outdoor unit. Systems offer energy efficiency levels up to 21 SEER2 and 10 HSPF2 for enhanced home comfort and energy savings. Daikin AURORA Multi-Zone systems offer enhanced capacity in cold ambient conditions. Suitable for both new build and renovation projects, Daikin Multi-Zone Systems are the smart, reliable solution for your home.
Features:
- Up to 24,000 BTU's - See Combination Capacity Chart here
- Pre-Charged for 98.4 ft of line set length
- World-renowned Daikin Inverter Variable Speed compressor technology
- Designed to deliver enhanced capacity in cold ambient conditions
- Up to 114% rated heating capacity at 5°F / -15°C and operate efficiently as low as -13°F ambient temperature (See full operating temperature details here)
- Energy Efficient - UP to 21 SEER2 / 10 HSPF2 / 12 EER2 for ultra-efficient cooling and heating operation and reduced operating costs compared to conventional lower-efficiency systems
- 2 Zone enhanced Capacity Multi-Zone
- R-32 Refrigerant Type
Specifications:
| Brand | Daikin |
| Model | 2MXT18AVJU9 |
| Warranty | 12 Year limited parts warranty with online registration. Click here for full warranty details |
| BTU | 18,000 BTU (Up to 24,000 BTU) - See Combination Capacity Chart here |
| Power Supply |
|
| COP@5°F | W/W: 1.8 |
| EER2 (Btu/W·h) |
12.0 |
| SEER2 | 21.0 |
| HSPF2 | 10.0 |
| Casing Color | Ivory White |
| Compressor |
|
| Refrigerant Oil |
|
| Refrigerant |
|
| Airflow Rates |
|
| Fan |
|
| Starting Current | 17 A |
| Dimensions (H × W × D) | 29-1/2 × 34-1/4 × 12-5/8 inches (750 × 870 × 320 mm) |
| Packaged Dimensions (H × W × D) | 32-1/16 × 40-5/16 × 16 inches (814 × 1,024 × 406 mm) |
| Weight (Mass) | 139 lbs (63 kg) |
| Gross Weight (Gross Mass) | 147 lbs (67 kg) |
| Sound Pressure Level |
|
| Piping Connection (inches) |
|
| Heat Insulation | Both Liquid and Gas Pipes |
| No. of Wiring Connections | 3 for Power Supply, 4 for Interunit Wiring (Including Ground Wiring) |
| Max. Interunit Piping Length |
|
| Amount of Additional Charge oz/ft(g/m) | 0.22 (20) (98-3/8 ft (30 m) or more) |
| Max. Installation Height Difference |
|
| Conditions Based on Cooling |
|
| Conditions Based on Heating |
|
|
Resources |
