The HVAC Mirage OFWB120D (WINTEK Series) is a high-performance 18 SEER2 Condenser engineered for quiet, high-efficiency heating and cooling in residential and commercial spaces.
Product Specifications & Resources:
- Cooling Capacity: 12000 BTU
- Efficiency Rating: 18 SEER2
- Electrical Voltage: 110V (60Hz Single Phase)
- Refrigerant Compliance: R-454B / Low-GWP 2026 Mandate Compliant
- Submittal Documentation: Download Factory Specs & Submittal Sheet (PDF)
Technical Performance Table
| Attribute | Specification |
|---|---|
| Model / Part SKU | OFWB120D |
| Product Family | HVAC Mirage WINTEK (SINGLE ZONES - R32) |
| Equipment Type | Condenser |
| Cooling Capacity | 12000 BTU |
| SEER2 Efficiency | 18 SEER2 |
| Operating Voltage | 110V |
| Refrigerant Type | R-454B / Low-GWP Eco-Friendly |
| Warranty Coverage | Standard Manufacturer Limited Warranty |
Pro-Installer Field Tip
Field Note: When performing installation on HVAC Mirage WINTEK units, ensure flare fittings are torqued to factory specifications and hold a vacuum below 500 microns for 15 minutes before opening service valves. Use 14/4 AWG stranded wire between indoor and outdoor sections to prevent communication codes.
